BP-165

- 6.5”2-Way Component Speaker System

- Black PP Mica Cone

- RMS Power: 35W

- Max Power: 70W

- Frequency Response: 55-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 88dB

- 25mm copper voice coil



BP-165C

- 6.5”2-Way Coaxial Speaker

- Black PP Mica Cone

- RMS Power: 35W

- Max Power: 70W

- Frequency Response: 55-20kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 88dB

- 25mm copper voice coil



BM6.5C

- 6.5”2-Way Component Speaker System

- 6.5 Inch Customed Tooling

- Glass Fiber Reinforced Cone

- Reversed Magnet Motor System Structure

- Much Slim Thickness, VS the Normal Speaker

- Much Heat Sink for Neodymium with More Hole

- RMS Power: 75W

- Max Power: 150W

- Qts : 0.75

- Frequency Response: 52-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90dB

- 38mm copper voice coil, OFC edge wound



SQ6.5C

- High End 6.5”2-Way Component Speaker System

- High Polishing Cap with Laser Technology

- Glass Fiber Reinforced Cone

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.6

- Frequency Response: 59-22kHz

- Nominal Impedance: 4 ohms

- Sensitivity(SPL/1W/1m): 90dB

- 25mm copper voice coil, OFC edge wound


BSM WOODPACKAGE_all.png

DIRECT (BSM)

- The Best High-end 6.5” 2-Way Component Speaker System

- 6.5 Inch midbass device for very high performance sound system

- Pear Coated White Ceramic Paper Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 50mm Aluminum Ribbon Voice Coil

- Real High-End 1.3” Silk Doped Dome Tweeter

- 18/24db Bi-Amping Crossover for Each Device

- RMS Power: 80W

- Max Power: 160W

- Qts: 0.577

- Frequency Response: 60-22kHz

- Nominal Impedance: 4 ohms

- Sensitivity(SPL/1W/1m): 90±3dB



DIRECT (BSM) SPECIAL

- A limited Production commemorative model

- The Best High-end 6.5” 2-Way Component Speaker System

- 6.5 Inch midbass device for very high performance sound system

- Pear Coated White Ceramic Paper Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 50mm Aluminum Ribbon Voice Coil

- Limited High-End 1.3”Yellow Silk Dome Tweeter with Diecasting Housing

- 18/24db Bi-Amping Crossover for Each Device

- RMS Power: 80W

- Max Power: 160W

- Qts: 0.577

- Frequency Response: 60-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90±3dB



DIRECT (BB)

- 6” 2-Way Component Speaker System That Invites You To The World Of Car Audio

- 6 Inch midbass device for very high performance sound system

- Real Black Kevla Cone with Composite - Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 25mm Two Layer Aluminum Ribbon Voice Coil

- 1” Silk Dome Tweeter

- 12db Crossover

- RMS Power: 50W

- Max Power: 100W

- Qts : 0.416

- Frequency Response: 68-20kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90dB



DIRECT (EL)

- 6.5” 2-Way Component Speaker System Plays The Extreme Bass.

- 6.5 Inch midbass device for very high performance sound system

- Real Black Kevla Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 35mm Two Layer Aluminum Ribbon Voice Coil

- High-End 1” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.376

- Frequency Response: 55-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 91dB



DIRECT (FRM)

- 6.5” 2-Way Component Speaker System Plays The Most Perfect Sound

- 6.5 Inch Full-Range device for very high performance sound system

- Real Black Kevla Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 55mm Two Layer Aluminum Ribbon Voice Coil

- HF-30D High-End 1.3” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.397

- Frequency Response: 65-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90dB



DIRECT (FRM) ANNIVERSARY

- Limited Production Model To Celebrate Its 40th Anniversary

- 6.5” 2-Way Component Speaker System Plays The Most Perfect Sound

- 6.5 Inch Full-Range device for very high performance sound system

- Innocence Yellow Kevla Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 55mm Two Layer Aluminum Ribbon Voice Coil

- HF-30B High-End 1.3” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.299

- Frequency Response: 52-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 92dB



DIRECT (MX)

- 6.5” 2-Way Component Speaker System Plays Fantastic Sound.

- 6.5 Inch midbass device for very high performance sound system

- Black Kevla Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 55mm Two Layer Aluminum Ribbon Voice Coil

- HF-25D High-End 1” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 100W

- Max Power: 200W

- Qts: 0.260

- Frequency Response: 69-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 91dB



DIRECT (XL)

- 6.5” 2-Way Component Speaker System

- 6.5 Inch midbass device for Amazing sound system

- Yellow Kevla Cone with Composite Rubber Edge Glass

- Aluminum Diecasting Frame with Cavity Vents

- 35mm Two Layer Aluminum Ribbon Voice Coil

- HF-25D High-End 1” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.416

- Frequency Response: 65-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90dB



DIRECT (XL) SPECIAL

- 6.5” 2-Way Component Speaker System

- 6.5 Inch midbass device for Amazing sound system

- Yellow Kevla Cone with Composite Rubber Edge Glass

- Aluminum Diecasting Frame with Cavity Vents

- 35mm Two Layer Aluminum Ribbon Voice Coil

- HF-25D High-End 1” Silk Doped Dome Tweeter

- Easy-To-Work Line Passive Crossover

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.416

- Frequency Response: 65-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 90dB



DIRECT (ZL)

- 6.5” 2-Way Component Speaker System Plays The Most Exciting Sound.

- 6.5 Inch midbass device for very high performance sound system

- Orange Kevla Cone with Composite Rubber Edge Glass

- Black Diecasting Frame with Cavity Vents

- 35mm Two Layer Aluminum Ribbon Voice Coil

- HF-25D High-End 1” Silk Doped Dome Tweeter

- 12/18db Bi-Amping Crossover for Each Device

- RMS Power: 60W

- Max Power: 120W

- Qts: 0.376

- Frequency Response: 55-22kHz

- Nominal Impedance : 4 ohms

- Sensitivity(SPL/1W/1m): 91dB


BSM160 Tristar.JPG

TRI-STAR (BSM)



G1 NUNAVUT

- 6.5”2-Way Component Speaker System
- 6.5 Inch Customed Tooling
- Glass Fiber Reinforced Cone
- Gold Polishing Cap with Laser Technology
- Optimized Crossover for Each Unit
- RMS Power40W
- Max Power90W
- Qts : 0.75
- Frequency Response: 55-22kHz
- Nominal Impedance: 2.8 ohms
- Sensitivity(SPL/1W/1m): 89±3dB
- 25mm copper voice coil, OFC edge wound



EXPRESS (MX)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 120-22kHz

- RMS Power: 60W

- Max Power: 150W

- Sensitivity(SPL/1W/1m): 93dB

- 35mm Two Layer Aluminum Ribbon Voice Coil

- 28.3oz Ferrite Magnet

- Black PP Mica Cone

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-25D High-End 1” Silk Doped Dome Tweeter

- Nominal Impedance: 4 ohms



EXPRESS (LX)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 110-22kHz

- RMS Power: 100W

- Max Power: 150W

- Sensitivity(SPL/1W/1m): 92dB

- 50mm Two Layer Aluminum Ribbon Voice Coil

- 28.3oz Ferrite Magnet

- Black PP Mica Cone

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-25D High-End 1” Silk Doped Dome Tweeter

- Nominal Impedance: 4 ohms



EXPRESS (EL)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 105-22kHz

- RMS Power:60W

- Max Power:150W

- Sensitivity(SPL/1W/1m): 91dB

- 35mm Two Layer Aluminum Ribbon Voice Coil

- 20oz Ferrite Magnet

- Black PP Mica Cone

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-25D High-End 1” Silk Doped Dome Tweeter

- Nominal Impedance: 4 ohms



EXPRESS (XL)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 120-22kHz

- RMS Power: 40W

- Max Power: 120W

- Sensitivity(SPL/1W/1m): 91dB

- 25mm Two Layer Aluminum Ribbon Voice Coil

- 13oz Ferrite Magnet

- Yellow Fiberglass Cone

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-25D High-End 1” Silk Doped Dome Tweeter

- Nominal Impedance: 4 ohms



EXPRESS (BSM)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 90-22kHz

- RMS Power: 90W

- Max Power: 150W

- Sensitivity(SPL/1W/1m): 87dB

- 50mm Two Layer Aluminum Ribbon Voice Coil

- 23.5oz Ferrite Magnet

- Pear Coated White Ceramic Paper Cone with Composite Rubber Edge Glass

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-30B High-End 1.25” Silk Dome Tweeter

- Nominal Impedance: 4 ohms



EXPRESS (FRM)

- 5.25” 2-Way Component Speaker System

- Frequency Range: 110-22kHz

- RMS Power: 60W

- Max Power: 120W

- Sensitivity(SPL/1W/1m): 90dB

- 35mm Two Layer Aluminum Ribbon Voice Coil

- 20oz Ferrite Magnet

- Yellow Kevlar Cone

- Black Diecasting Aluminum Frame with Cavity Vents

- HF-30D 1.25” Silk Dome Tweeter

- Nominal Impedance: 4 ohms
